Machinable Fine Zirconium Dioxide Ceramic Rod Shaft Pin Plate Parts Electronic

Product Details

Place of Origin: Made in China

Brand Name: wuxi special ceramic

Payment & Shipping Terms

Minimum Order Quantity: 10p

Price: us$0.1~us$10/p

Packaging Details: carton,wooden,box,pallet

Delivery Time: negotiable

Payment Terms: T/T

Supply Ability: 10000P/Month

Get Best Price
High Light:

Zirconium Dioxide Ceramic Rod

,

Zirconium Dioxide Ceramic Shaft

,

Zirconium Dioxide Ceramic Pin

Place Of Origin:
Jiangsu China
Type:
Ceramic Raw Materials
Application:
Ceramic Decorations
Material:
Zirconia Ceramic
Color:
White/black
Shape:
Customized
Feature:
High Wear-resistance
Raw Material:
Zirconia,alumina,silicon Nitride
Name:
Industrial Ceramic
Property:
Acid Resistant
Surface:
Polishing Finish
Place Of Origin:
Jiangsu China
Type:
Ceramic Raw Materials
Application:
Ceramic Decorations
Material:
Zirconia Ceramic
Color:
White/black
Shape:
Customized
Feature:
High Wear-resistance
Raw Material:
Zirconia,alumina,silicon Nitride
Name:
Industrial Ceramic
Property:
Acid Resistant
Surface:
Polishing Finish
Machinable Fine Zirconium Dioxide Ceramic Rod Shaft Pin Plate Parts Electronic

Precision ceramic in rod,shaft,pin,plate and other machinable part.



Wuxi Special special Ceramic Co., Ltd is a company dedicated to the professional fine ceramic manufacture. We specialize in the design and manufacture of aluminum oxide,zirconium oxide and silicon nitride ceramic product. The main products include Ceramic Plungers,Ceramic Ball Valves,Ceramic rods,Ceramic Nozzles,Ceramic Plates and other Industrial Ceramic Products.



data sheet for zirconia ceramic

Item Unit Typical Values
Physical Properties
Color Customized
Density g/cm3 6
Zirconia Content % 94.40%
Gas permeability 0
Water Absorption 0
Crystal Size um 0.5
Mechanical Properties
Rockwell Hardness(45N) R45N 78
Vickers Hardness (Load 500g) Gpa(Kg/mm²) 11.5(1175)
Flexural Strength(20°C) Mpa 800
Compressive Strength(20°C) Mpa 2000
Modulus of Elasticity(20°C) Gpa >200
Fracture Toughness(20°C) MPam1/2 9
Thermal Properties
Thermal Conductivity(20°C-400°C) W(m.K) 2.5
Thermal Expansion Coefficient 10-6/°C 9.6
Thermal Shock Resistance T°C 250



Alumina Ceramic Properties 96% Alumina Ceramic 99% Alumina Ceramic
Item Unit Typical Values
Physical Properties
Color   White Ivory
Density g/cm3 3.7 3.85
Alumina Content % 96% 99%
Gas permeability   0 0
Water Absorption   0 0
Mechanical Properties
MONS' Hardness Grade 9 9
Rockwell Hardness HRA 80 82
Vickers Hardness (Hv50) Gpa(Kg/mm²) 15.7(1600) 15.7(1600)
Flexural Strength(20°C) Mpa 300 330
Compressive Strength(20°C) Mpa 2000 2000
Modulus of Elasticity Gpa 275
Poisson's Ratio (20°C)   0.22-0.23
Fracture Toughness(20°C) MPam1/2 3.5 4
Thermal Properties
Thermal Conductivity(20°C-400°C) W(m.K) 25 27.5
Thermal Expansion 10-6/°C 6.5-7.5 7.6
Maximum Use Temperature °C 1600 1650
Electronic Properties
Dielectric KV/mm >12 >10
Dielectric Constant Er 9-10 9.1
Dielectric Loss Angle(1MHz)   0.0002 0.0002-0.0003



We develop fine ceramic products which are widely used in machinery, semiconductor, aerospace, petroleum, chemical, electronics, medical, fluid control, food and other industries. The superior electrical characteristics of fine ceramics are utilized in a variety of circuit boards and electronic parts. Their wear and corrosion resistance is beneficial in pumps nozzles and valve parts, and their high heat and thermal shock resistance is useful in ceramic engine parts.



Properties of Silicon Nitride (Si3N4) Ceramics
Item Unit Typical Values
Physical Properties
Density g/cm3 >3.2
Mechanical Properties
Rockwell Hardness   HRA90
Vickers Hardness (Hv50) HV0.5 >1550
Modulus of Elasticity Gpa 290
Flexural Strength Mpa >600
Compressive Strength Mpa 2500
Fracture toughness Mpam1/2 >6.0
Thermal Properties
Maximum use temperature °C 1200
Thermal Conductivity W/(m.k) 15-20
Thermal Expansion Coefficient 10-6/°C >3.1
Thermal Shock Resistance T°C 500
Specific Heat Capacity KJ/kg.K 700
Electrical Properties
Dielectric Strength KV/mm 1



Machinable Fine Zirconium Dioxide Ceramic Rod Shaft Pin Plate Parts Electronic 0Machinable Fine Zirconium Dioxide Ceramic Rod Shaft Pin Plate Parts Electronic 1Machinable Fine Zirconium Dioxide Ceramic Rod Shaft Pin Plate Parts Electronic 2Machinable Fine Zirconium Dioxide Ceramic Rod Shaft Pin Plate Parts Electronic 3Machinable Fine Zirconium Dioxide Ceramic Rod Shaft Pin Plate Parts Electronic 4Machinable Fine Zirconium Dioxide Ceramic Rod Shaft Pin Plate Parts Electronic 5



Our service



Material Service:

Zirconia Ceramic: Mg-PSZ, Y-TZP, ZTA

Alumina Ceramic: 96%, 99%, 99.5% Al2O3

Silicon Nitride: Si3N4, RBSN, SRBSN, GPSN

Machinable Ceramic: Macor Ceramic



Machining Service:

Laser Cutting

CNC Machining

Cernerless Grinding and Inside Hole Honing

Surface Grinding and Polishing





Company Introduce



Wuxi Special Ceramic Electrical Co.,Ltd mainly produces alumina, Silicon nitride, Zirconia, Steatite, Boron nitride, Cordierite,mullite products, widely used in metal welding, electronic conductor, mechanics, assembling, insulation, chemicals, instrument, textile, nuclear industry, aerial field.We accept trial produce according to the drawing or sample.It usually takes 15 days to finish trial product.Mass produce usually takes 30 days.Goods' package is carton or PLT.It can be negotiable with each other.
We mainly sell goods to toshiba lighting group in Japan and Europe.Our aim is to deliver goods with high quality at quick delivery date.



mass production by 100% inspection
