Textile Machinery Parts Textile Thread Guide Eyelet Ceramic Wire Guide Eyelet

Textile Machinery Parts Textile Thread Guide Eyelet Ceramic Wire Guide Eyelet

  • Textile Machinery Parts Textile Thread Guide Eyelet Ceramic Wire Guide Eyelet
  • Textile Machinery Parts Textile Thread Guide Eyelet Ceramic Wire Guide Eyelet
  • Textile Machinery Parts Textile Thread Guide Eyelet Ceramic Wire Guide Eyelet
  • Textile Machinery Parts Textile Thread Guide Eyelet Ceramic Wire Guide Eyelet
Textile Machinery Parts Textile Thread Guide Eyelet Ceramic Wire Guide Eyelet
Product Details:
Place of Origin: Made in China
Brand Name: wuxi special ceramic
Model Number: rings
Payment & Shipping Terms:
Minimum Order Quantity: 10p
Price: us$0.1~us$10/p
Packaging Details: carton,pallet
Delivery Time: negotiable
Payment Terms: T/T
Supply Ability: 200000p/month
Contact Now
Detailed Product Description
Application: Industiral Application, Textile Machinery Color: White,pink,black,yellow
Material: 95%-99% Alumina Ceramic Property: Wear Resistance And Low Friction
Processing Service: Moulding,punching,cutting Place Of Origin: China
Working Temperature: 1200~1500℃ Feature: Acid And Corrosion Resistance
High Light:

Textile Machinery Parts Thread Guide Eyelet

,

99% Alumina Ceramic Wire Guide Eyelet

,

Guide Eyelet Textile Machinery Parts

Factory Supply Textile Machinery Parts Various Size Textile Thread Guide Eyelet Ceramic Wire Guide Eyelet

Alumina(Al2O3)Textile Ceramic Eyelets



Alumina ceramic is kind of structural ceramics, with insulation resistance, voltage resistance, high strength, good thermal conductivity, dielectric loss, stable electrical performance characteristics. Used in electronic ceramic substrates, ceramic electrical insulation, vacuum devices, devices porcelain, spark plugs and other products.
We can supply the products according to customer's drawings, samples and performance requirement.



Ceramic Eyelets Features
A. High hardness.
B. High heat resistance : Alumina ceramic has execellent themal stability,which means that it is widely used in areas where resistance to high temperatures is essential.
C. Good wear resistance : Alumina ceramic is the material of choice for alumina wear parts.



Ceramic Eyelets Application
A. Knitting Machine
B. Winder Guides for PA thread
C. Twisting Machinery
D. Sensible fiber at low speed
E. Sensible fiber at high speed
F. Weaving machinery
G. Texturing machinery



Specification

Material code characteristics Density(g/cm³) Young's Moulus(GPa) Flexural strength(MPa) Fracture Toughness(MPa*m1/2) Thermal Expansion RT~800°) Thermal Conductivity(w/m*k) Volume Resistivity(Ω*cm)
ALP01 General Purpose High Rigidiy 3.9 370 440 3~4 7.7 33 >10⋀14
Alumina99.5%
ALP02 High Purity High Rigidity 3.9 370 450 3~4 7.9 30 >10⋀14
Alumina99.9%



Textile Machinery Parts Textile Thread Guide Eyelet Ceramic Wire Guide Eyelet 0

Our Company


Wuxi Special Ceramic Electrical mainly produces alumina, Silicon nitride, Zirconia, Steatite, Boron nitride, Cordierite,mullite products, widely used in metal welding, electronic conductor, mechanics, assembling, insulation, chemicals, instrument, textile, nuclear industry, aerial field.We accept trial produce according to the drawing or sample.It usually takes 15 days to finish trial product.Mass produce usually takes 30 days.Goods' package is carton or PLT.It can be negotiable with each other.
We mainly sell goods to toshiba lighting group in Japan and Europe.Our aim is to deliver goods with high quality at quick delivery date.







Textile Machinery Parts Textile Thread Guide Eyelet Ceramic Wire Guide Eyelet 1

Textile Machinery Parts Textile Thread Guide Eyelet Ceramic Wire Guide Eyelet 2



   quality guarantee:mass produce by 100% inspection
