Product Details
Place of Origin: China
Brand Name: Wuxi Special Ceramic
Payment & Shipping Terms
Minimum Order Quantity: 10p
Price: 1usd
Packaging Details: carton/pallet
Delivery Time: 15-30days
Payment Terms: L/C, T/T
Supply Ability: 100000p/month
Dielectric Constant: |
9 |
Maximum Use Temperature: |
1700℃ |
Flexural Strength: |
≥330MPa |
Density: |
3.4-3.6g/cm3 |
Arc Resistance: |
>30min |
Thermal Expansion: |
4.5-5.5x10-6/K |
Material: |
Aluminum Nitride Ceramic |
Thermal Conductivity: |
≥170W/m.K |
Dielectric Constant: |
9 |
Maximum Use Temperature: |
1700℃ |
Flexural Strength: |
≥330MPa |
Density: |
3.4-3.6g/cm3 |
Arc Resistance: |
>30min |
Thermal Expansion: |
4.5-5.5x10-6/K |
Material: |
Aluminum Nitride Ceramic |
Thermal Conductivity: |
≥170W/m.K |
Aluminium Nitride Ceramic is a highly advanced material that is widely used in a variety of industries. It is made from aluminium nitride and is known for its superb properties such as high hardness (HV1500), high density (3.4-3.6 g/cm3), excellent thermal conductivity (≥170 W/m.K), high maximum use temperature (1700℃), and remarkable volume resistivity (>1014 Ω.cm). It is the perfect choice for any application that requires high performance and reliability. Aluminium Nitride Ceramic is also ideal for the manufacturing of alumina-nitride-ceramic structure parts, as its properties make it the perfect material for creating highly durable and accurate parts. Aluminium-nitride-ceramic parts are perfect for any industry that needs high-quality parts that can withstand the most extreme conditions.
Property | Value |
---|---|
Arc Resistance | >30min |
Compressive Strength | 1000-1500MPa |
Density | 3.4-3.6g/cm3 |
Flexural Strength | >=330MPa |
Maximum Use Temperature | 1700℃ |
Thermal Conductivity | >=170W/m.K |
Dielectric Strength | >=15KV/mm |
Material | Aluminium Nitride Ceramic |
Volume Resistivity | >1014Ω.cm |
Hardness | HV1500 |
Wuxi Special Ceramic's Aluminium Nitride Ceramic is a highly durable material, made of aluminium nitride, with a hardness of HV1500. It is produced in China and has excellent chemical resistance, and a maximum use temperature of 1700℃. The Aluminium Nitride Ceramic has a gray color and is suitable for many applications, including Alumina-Nitride-Ceramic pipes, Alumina-Nitride-Ceramic structure parts and Alumina-Nitride-Ceramic electronics components.
Due to its high strength and hardness, Aluminium Nitride Ceramic is ideal for applications that require a long-lasting and reliable material. It can be used in a variety of industries, such as automotive, medical, and electronics. In particular, it is well-suited for high-temperature and corrosive environments, due to its excellent chemical resistance. The Aluminium Nitride Ceramic is also highly resistant to heat, making it ideal for the production of parts that need to withstand high temperatures.
Aluminium Nitride Ceramic is also suitable for use in a wide range of electronics components, such as RF antennas and microwave components. It is a very cost-effective material, as it is highly durable and can be used in a variety of applications. In addition, it is a lightweight material, making it easy to transport and install.
Overall, Wuxi Special Ceramic's Aluminium Nitride Ceramic is a highly reliable and cost-effective material that is suitable for a wide range of applications. It is a strong and durable material that can withstand high temperatures and corrosive environments, making it perfect for many industrial applications.
Wuxi Special Ceramic is offering customized Aluminium Nitride Ceramic services, with the following features:
We provide various shapes and sizes of Alumina-Nitride-Ceramic products, including plate, tube, rod and block.
We provide technical support and service to ensure that our customers get the most out of their Aluminium Nitride Ceramic products.
We offer free technical consultation services to help customers understand the capabilities and features of the product. Our technical support staff are available to answer questions and provide assistance to customers. We also provide product updates and software upgrades to ensure that customers are using the latest version of the product.
We also offer product maintenance services to keep our customers’ products running smoothly. Our technical team can troubleshoot any issues that arise and provide solutions to ensure that our customers’ products are running optimally.
If you have any questions or concerns about Aluminium Nitride Ceramic, please contact us. We are here to help.
Aluminium Nitride Ceramic is typically packaged and shipped as individual ceramic pieces, with the product being secured in a box with foam cushioning. The box is then sealed and labeled with a shipping label.
The box is usually placed in a larger shipping container, such as a wooden crate or cardboard box, to ensure that the product is protected during shipment. The container is then sealed and labeled with a shipping label.
The product is then loaded onto a cargo truck or aircraft for shipment. The product is usually tracked using a tracking number, which can be used to monitor the progress of the shipment.
