Product Details
Place of Origin: China
Brand Name: wuxi special ceramic
Payment & Shipping Terms
Minimum Order Quantity: 10p
Price: 1usd
Packaging Details: carton/pallet
Delivery Time: 30days
Payment Terms: L/C, T/T
Supply Ability: 100000p/month
Hardness: |
9 Mohs |
Material: |
Al2O3 Ceramic |
Insulation Resistance: |
1012 Ω·cm |
Flexural Strength: |
400 MPa |
Thermal Expansion: |
7.2 X 10-6/K |
Density: |
3.8-3.9 G/cm3 |
Volume Resistivity: |
1014 Ω·cm |
Tensile Strength: |
300 MPa |
Hardness: |
9 Mohs |
Material: |
Al2O3 Ceramic |
Insulation Resistance: |
1012 Ω·cm |
Flexural Strength: |
400 MPa |
Thermal Expansion: |
7.2 X 10-6/K |
Density: |
3.8-3.9 G/cm3 |
Volume Resistivity: |
1014 Ω·cm |
Tensile Strength: |
300 MPa |
Al2O3 Ceramic is an aluminium oxide ceramic material which has a density of 3.8-3.9 G/cm3, a dielectric constant of 9.6, a breakdown voltage of 20 KV/mm, and a compressive strength of 3000 MPa. This Al2O3 ceramic material has excellent electrical insulation properties, high thermal conductivity, and good mechanical strength. It is also resistant to high temperatures, making it an ideal choice for high-temperature applications. Furthermore, this material is non-toxic and environmentally friendly. Al2O3 Ceramic is one of the most reliable and cost-effective materials available, making it an ideal choice for a variety of applications.
| Property | Value |
|---|---|
| Insulation Resistance | 1012 Ω·cm |
| Dielectric Constant | 9.6 |
| Young's Modulus | 320 GPa |
| Compressive Strength | 3000 MPa |
| Tensile Strength | 300 MPa |
| Hardness | 9 Mohs |
| Material | Al2O3 Ceramic (Aluminum Oxide Ceramic, Alumina Oxide Ceramics) |
| Density | 3.8-3.9 G/cm3 |
| Flexural Strength | 400 MPa |
| Volume Resistivity | 1014 Ω·cm |
Wuxi Special Ceramic is the brand name of aluminum oxide ceramics from China. It is world renowned for its high density of 3.8-3.9 G/cm3, breakdown voltage of 20 KV/mm, volume resistivity of 1014 Ω·cm, insulation resistance of 1012 Ω·cm, and hardness of 9 Mohs. The alumina oxide ceramics provide superior insulation performance and can be used in a variety of applications, including electrical, electronic, chemical, and medical equipment, as well as automotive, aerospace, and military components. Wuxi Special Ceramic has a wide range of products that can meet the needs of any application. The alumina oxide ceramics are ideal for use in high temperature, high pressure, and extreme environmental conditions, making them suitable for a wide range of applications. From heat exchangers to automotive components, Wuxi Special Ceramic alumina oxide ceramics can provide the perfect solution for any need.
Aluminium Oxide Ceramics, Aluminium Oxide Ceramic, Alumina Oxide Ceramics, Alumina Oxide Ceramic are the key words of this product.
We provide comprehensive technical support and service for our Al2O3 Ceramic products. Our service includes:
For more information, please contact us at info@example.com.
Al2O3 Ceramic Packaging and Shipping:
The Al2O3 ceramic is packaged using appropriate materials such as cardboard boxes, foam, bubble wrap, and shrink wrap. The ceramic is then securely placed in the box and sealed before shipment. The box is labeled with a shipping label that contains the product details, the destination address, and a tracking number for the shipment. For shipping, we use a reliable courier service such as FedEx, UPS, or DHL to ensure that the package is delivered promptly and safely.
