High Purity 96% Alumina Ceramic Shaft Heater Insulators Ring Tube Plate Rod Thread Part

High Purity 96% Alumina Ceramic Shaft Heater Insulators Ring Tube Plate Rod Thread Part

  • High Purity 96% Alumina Ceramic Shaft Heater Insulators Ring Tube Plate Rod Thread Part
  • High Purity 96% Alumina Ceramic Shaft Heater Insulators Ring Tube Plate Rod Thread Part
  • High Purity 96% Alumina Ceramic Shaft Heater Insulators Ring Tube Plate Rod Thread Part
High Purity 96% Alumina Ceramic Shaft Heater Insulators Ring Tube Plate Rod Thread Part
Product Details:
Place of Origin: Made in China
Brand Name: wuxi special ceramic
Payment & Shipping Terms:
Minimum Order Quantity: 10p
Price: us$1~us$1000/P
Packaging Details: carton,wooden,box,pallet
Delivery Time: negotiable
Payment Terms: T/T
Supply Ability: 10000P/Month
Contact Now
Detailed Product Description
Place Of Origin: Jiangsu China Type: Ceramic Rods
Application: Industrial Ceramic Material: Alumina Ceramic,95~99% Al2O3
Color: White/ivory Shape: Rod/ring/tube/plate/block/parts
Density: 3.65~3.85g/cm3 Size: According To The Drawing
Max Working Temperature: 1100~1650℃ Property: High Temperature Resistance
High Light:

Alumina Ceramic Shaft

,

Alumina Ceramic Heater

,

96 Alumina Ceramics

Insulators Ceramic Ring/Tube/Rod/Plate thread part Supplier



Advanced ceramic application propect are very widely.Such as be used in aerospace,aviation,military industry,nuclear power,machinery,texile,chemical,electronic,food,medical,ect.



Alumina Ceramic Properties 96% Alumina Ceramic 99% Alumina Ceramic
Item Unit Typical Values
Physical Properties
Color   White Ivory
Density g/cm3 3.7 3.85
Alumina Content % 96% 99%
Gas permeability   0 0
Water Absorption   0 0
Mechanical Properties
MONS' Hardness Grade 9 9
Rockwell Hardness HRA 80 82
Vickers Hardness (Hv50) Gpa(Kg/mm²) 15.7(1600) 15.7(1600)
Flexural Strength(20°C) Mpa 300 330
Compressive Strength(20°C) Mpa 2000 2000
Modulus of Elasticity Gpa 275
Poisson's Ratio (20°C)   0.22-0.23
Fracture Toughness(20°C) MPam1/2 3.5 4
Thermal Properties
Thermal Conductivity(20°C-400°C) W(m.K) 25 27.5
Thermal Expansion 10-6/°C 6.5-7.5 7.6
Maximum Use Temperature °C 1600 1650
Electronic Properties
Dielectric KV/mm >12 >10
Dielectric Constant Er 9-10 9.1
Dielectric Loss Angle(1MHz)   0.0002 0.0002-0.0003





Product feature

Compared with metal materials, the advanced ceramic with high hardness, high strength, high temperature, wear resistance, corrosion resistance, acid and alkali resistance, oxidation resistance, insulation, nonmagnetic, good chemical stability and other excellent performances.



High Purity 96% Alumina Ceramic Shaft Heater Insulators Ring Tube Plate Rod Thread Part 0







Our services



Material Service:

Zirconia Ceramic: Mg-PSZ, Y-TZP, ZTA

Alumina Ceramic: 96%, 99%, 99.5% Al2O3

Silicon Nitride: Si3N4, RBSN, SRBSN, GPSN

Machinable Ceramic: Macor Ceramic



Machining Service:

Laser Cutting

CNC Machining

Cernerless Grinding and Inside Hole Honing

Surface Grinding and Polishing



Company introduce

Wuxi Special Ceramic Electrical Co.,Ltd mainly produces alumina, Silicon nitride, Zirconia, Steatite, Boron nitride, Cordierite,mullite products, widely used in metal welding, electronic conductor, mechanics, assembling, insulation, chemicals, instrument, textile, nuclear industry, aerial field.We accept trial produce according to the drawing or sample.It usually takes 15 days to finish trial product.Mass produce usually takes 30 days.Goods' package is carton or PLT.It can be negotiable with each other.
We mainly sell goods to toshiba lighting group in Japan and Europe.Our aim is to deliver goods with high quality at quick delivery date.



mass production by 100% inspection

High Purity 96% Alumina Ceramic Shaft Heater Insulators Ring Tube Plate Rod Thread Part 1



High Purity 96% Alumina Ceramic Shaft Heater Insulators Ring Tube Plate Rod Thread Part 2
